Ziggy 20
Ziggy 20
Supply
- Static white 500mA
Power
- 18W
Photometrics
F606
15°soft
F607
15°tight
F608
24°
F609
36°
F610
60°
F611
OVAL
G
F455
120dg
Color Temperature / Luminous flux
| 2700K | 2165lm |
| 3000K | 2279lm |
| 3500K | 2498lm |
| 4000K | 2423lm |
COB LED equipped; IP67-rated; recessed fixtures of the highest build quality; extremely compact dimensions and high output. Recessed optics guarantee high viewing comfort. Fully anodized aluminium body; versions with front in walkable powder-coated anodized aluminium. Extra-clear tempered glass; ATEX cable gland; neoprene cable. Revolutionary in dissipative; functional design; they offer the possibility to combine colour temperatures and beam angles in CRI 98. Can be installed with anti-glare filter for maximum viewing comfort.
Code
Build your code by choosing each attribute
- ZG2
- -
- -
- -
- Copy Code
- Ziggy 20
Cct
Finish
Beam angle
Accessories
AT086RO2090
Airtight recessed housing for insulated ceiling
IC086RO2090
Recessed housing for insulated ceiling
MP-R090
Baseplate
RO2090
T-bar baseplate
ZQC006
Plasterboard recessing frame
Drivers
Static white 500mA
Code
Build your code by choosing each attribute
Cct
Finish
Beam angle
- ZG2
- -
- -
- -
- Copy Code
- Ziggy 20
Accessories
AT086RO2090
Airtight recessed housing for insulated ceiling
IC086RO2090
Recessed housing for insulated ceiling
MP-R090
Baseplate
RO2090
T-bar baseplate
ZQC006
Plasterboard recessing frame
