Dig 20
Dig 20
Supply
- Static white 500mA
Power
- 18W
Photometrics
F606
15°soft
F607
15°tight
F608
24°
F609
36°
F610
60°
F611
OVAL
G
F455
120dg
Color Temperature / Luminous flux
| 2700K | 2165lm |
| 3000K | 2279lm |
| 3500K | 2498lm |
| 4000K | 2423lm |
IP67 uplight of the utmost build quality; combining extremely small dimensions with a high luminous flux. With a body in thick anodised aluminium; it comes in versions with the front in AISI316L stainless steel and anodised and powder-coated aluminium. Extra-clear tempered glass; ATEX cable gland and neoprene cable. With CRI 98 LEDs and highly-advanced optics; it offers narrow and precise light beams. The range of accessories includes the glare filter for maximum visual comfort.
Code
Build your code by choosing each attribute
- DIG2
- -
- -
- -
- Copy Code
- Dig 20
Cct
Finish
Beam angle
Accessories
CSXJ02
Recessing boot
CSXJ02.CP
Concrete pour housing for ingrade - 5x5x2 junction box
Drivers
Static white 500mA
Code
Build your code by choosing each attribute
Cct
Finish
Beam angle
- DIG2
- -
- -
- -
- Copy Code
- Dig 20
Accessories
CSXJ02
Recessing boot
CSXJ02.CP
Concrete pour housing for ingrade - 5x5x2 junction box
