TERA 6

IP67-rated, ground recessed fixtures of the highest build quality, extremely compact dimensions and high output. Fully anodized aluminium body, versions with front in vehicle-proof AISI 316L stainless steel and in walkable powder-coated anodized aluminium. Extra-clear tempered glass, ATEX cable gland, neoprene cable. Can be installed with anti-glare filter for maximum viewing comfort.
Photometrics
  • F005
    25°
  • F006
    60°
  • F035
    120°
Code

XT2

  • X
    shape1round2square
  • X
    beam angle125°260°
  • X
    color temperature272700K303000K353500K404000KCUCustom*
  • X
    FinishingGgreyNblackKCOR*ZINOX AISI 316L
  • E
Optionals
  • CSXT01

    Recessing box

  • CSXT01-RAB
  • L001

    Low luminace louvre

    Note:

    Note: the filter must be ordered together with the lighting fixture

Drivers
  • Phase
    FLEXA-12-500-CC-ELV_4.5W12W 500mA Constant CurrentDimming range: 10%Min.1/Max.2 Fixtures per Driver
    FLEXA-23-500-CC-ELV_4.5W23W 500mA Constant CurrentDimming range: 10%Min.3/Max.5 Fixtures per Driver
  • 0-10V
    FLEXA-60-PRO-CC-10V_4.5WProgrammable 60W CC 0-10V DimmingDimming range: 0.1%Min.1/Max.6 Fixtures per Driver
  • Lutron Ecosystem
    LDE.1_4.5WHi-Lume Ecosystem500mA Constant CurrentDimming range: 1%Min.2/Max.3 Fixtures per Driver
    LDE.2_4.5WHi-Lume Ecosystem Premier500mA Constant CurrentDimming range: 1%Min.4/Max.5 Fixtures per Driver
  • Lutron 2-Wire Phase
    LTEA.1_4.5WHi-Lume 2-Wire Phase500mA Constant CurrentDimming range: 1%Min.1/Max.2 Fixtures per Driver
    LTEA.2_4.5WHi-Lume 2-Wire Phase500mA Constant CurrentDimming range: 1%Min.2/Max.4 Fixtures per Driver
    LTEA.3_4.5WHi-Lume 2-Wire Phase500mA Constant CurrentDimming range: 1%Min.4/Max.6 Fixtures per Driver
